AFE

APPLICATION

Portable axial fan provided with combustion engine. The enclosure is made of welded steel sheet, powder painted. The impeller with blades and hub made of aluminum. Protective guards for inlet and outlet of the fan. Fan setting angle modification range: -25^o to +25^o.

Thanks to pneumatic wheels the fan can be easily transported anywhere, without the need to be carried. The fan is also equipped with an hour meter and tachometer, which allow you to control the fan operation time and its rotation speed.

Technical data of the AFE-500 fan

• Combustion engine: Honda GX160
• Yield up to 19 000 m3/h (at 3600 rev/min)
• Sound pressure level: 79 dB(A)*
• Operating time with full tank: 2,2 h (at 3600 rev/min)
• Weight: 51 kg
• Dimensions (L x W x H): 601 x 878 x 892 mm

* Sound pressure level measured at a distance of 20m in an open space, at full engine speed and at ambient sound pressure of 49 dB(A)

Technical data of Honda GX160 engine

• Engine type: four-stroke, OHV, air-cooled, horizontal shaft
• Cubic capacity: 163 cm3
• Bore x stroke: 68 x 45 mm
• Maximum power: 3.6 kW (4.8 hp) / 3600 rev/min
• Maximum torque: 10.3 Nm / 1.05 kgm / 2500 rev/min
• Ignition system: Electronic
• Starter: manual (optional: electric starter)
• Fuel tank capacity: 3.1 l
• Fuel consumption: 1.4 l / h (3600 rev/min)
• Oil capacity: 0.6 l
• Dimensions (L x W x H): 312 x 362 x 346mm
• Weight: 15 kg
